An exploration of ratios of parts of a triangle
- Use the point and segment tools to create a scalene triangle with vertices A, B, and C.
- Use the point on object tool to put point D anywhere on side AC.
- Use the parallel line tool to construct a line parallel to side AB through D.
- Use the intersect tool to create point E where your parallel line intersects side BC.
- Use the show/hide object tool to hide line DE and segments AC and BC. (This tool will give the impression it's just turning these part gray, when you click on the move tool again, they'll actually disappear
- Use the segment tool to create segments DE, AD, CD, BE, and CE and use the move tool and style bar to change the colors of these segments to easily distinguish which is which in the algebra window.
- Note that the length of each segment is listed along with a letter to represent it in the algebra window. Use the appropriate combinations of these letters in the input bar (at the bottom of the algebra window) to calculate the ratios and . The results of these calculations will appear as numbers near the top of the algebra window.
Use the move tool to drag around all draggable points in the diagram, keeping an eye on the ratios you had GeoGebra calculate for you in Step 7. What do you notice?
Propose a theorem to summarize what you've observed in this construction.
